True Deep Sleep: Achieving Suspend-Then-Hibernate on Kubuntu

Modern Linux distributions often default to s2idle (Modern Standby), which keeps the CPU in a shallow low-power state rather than fully powering down components. On laptops like Lenovo ThinkPads, this can result in significant battery drain while the lid is closed.

Furthermore, configuring a proper “Suspend-Then-Hibernate” workflow — where the laptop enters S3 sleep briefly for instant-wake, but eventually hibernates to save battery — often conflicts with desktop environment power managers like KDE’s PowerDevil.

This guide covers the complete configuration to force true hardware-level S3 deep sleep, enable proper NVMe power savings during idle, and bypass KDE to achieve reliable suspend-then-hibernate.

Prerequisites

#

1. BIOS/UEFI Configuration: Ensure your Sleep State is set to Linux S3 (not Windows 10/Modern Standby). On ThinkPads, this is found under Config → Power → Sleep State.
2. Secure Boot: Must be Disabled. The kernel’s Lockdown Mode (enforced when Secure Boot is active) prevents writing RAM contents to disk, which blocks hibernation entirely.

Step 1: Prepare the Swapfile for Hibernation

#

To hibernate, the kernel writes the contents of RAM to swap. Your swapfile must be at least as large as your physical RAM — slightly larger is recommended to account for memory compression overhead.

Create and initialize the swapfile (adjust the size to match your RAM — this example uses 18G for a 16GB system):

sudo fallocate -l 18G /swapfile
sudo chmod 600 /swapfile
sudo mkswap /swapfile
sudo swapon /swapfile

Btrfs users: fallocate creates files with holes on Btrfs, and the kernel will refuse to use them for hibernation. Use dd instead:

sudo dd if=/dev/zero of=/swapfile bs=1M count=18432 status=progress

Make it permanent by adding it to /etc/fstab:

echo '/swapfile none swap sw 0 0' | sudo tee -a /etc/fstab

Next, gather the UUID of your root partition and the physical offset of your swapfile. The kernel needs both to locate the swapfile on disk during resume.

# Get the UUID of the partition containing /swapfile
findmnt -no UUID -T /swapfile

# Get the physical offset
sudo filefrag -v /swapfile | awk 'NR==4 {print $4}' | tr -d '.'

Note down both values — you will need them in the next step.

Step 2: Configure GRUB (Boot Parameters)

#

The kernel needs to know where to find the hibernation image on resume. We pass the resume device and offset through GRUB.

Edit the GRUB configuration:

sudo nano /etc/default/grub

Update the GRUB_CMDLINE_LINUX_DEFAULT line (replace the UUID and offset with your own values from Step 1):

GRUB_CMDLINE_LINUX_DEFAULT="quiet splash pcie_aspm=force resume=UUID=YOUR-UUID-HERE resume_offset=YOUR-OFFSET-HERE"

What each parameter does

#

Intel-only option: If you are on an Intel system and want to be explicit about CPU C-state depth, you can add intel_idle.max_cstate=10. This parameter is specific to the intel_idle driver and has no effect on AMD systems. In practice, the driver already defaults to allowing all supported C-states, so this is rarely needed — but it does no harm on Intel.

Apply the changes:

sudo update-grub

A note on NVMe power states

#

You may see guides recommending nvme_core.default_ps_max_latency_us=5500 to “enable deep NVMe sleep.” This is misleading. That parameter sets a ceiling — power states with exit latency above the value are excluded. The kernel default is 100000 (100 ms), which already permits the deepest states on virtually all drives. Setting 5500 actually restricts your drive from entering its deepest idle states (typically PS4, which has exit latencies around 15 ms on many drives).

If your NVMe is behaving correctly, leave the default alone. If you suspect APST-related issues (drive disappearing after idle, system hangs on wake), the diagnostic step is:

# Check your drive's power state table
sudo nvme id-ctrl /dev/nvme0 -H | grep -A 3 "PS:"

# Check current APST configuration
sudo nvme get-feature /dev/nvme0 -f 0x0c -H

# Verify the kernel's current setting
cat /sys/module/nvme_core/parameters/default_ps_max_latency_us

Step 3: Configure Systemd Sleep and Lid Behavior

#

Define how long the system should stay in S3 sleep before transitioning to hibernation.

Edit the sleep configuration:

sudo nano /etc/systemd/sleep.conf

Add or uncomment the following lines:

[Sleep]
AllowSuspendThenHibernate=yes
HibernateMode=platform shutdown
HibernateDelaySec=120min

Important: You must include a time unit (min, h, s). If you write HibernateDelaySec=120 without a unit, systemd interprets it as 120 seconds — your laptop will hibernate almost immediately instead of sleeping for two hours.

Next, tell systemd what to do when the lid closes:

sudo nano /etc/systemd/logind.conf

Uncomment and set:

HandleLidSwitch=suspend-then-hibernate
HandleLidSwitchExternalPower=suspend-then-hibernate

Step 4: Bypassing KDE PowerDevil

#

This is the step most guides miss. KDE Plasma’s PowerDevil daemon intercepts lid-close events before systemd’s logind sees them. This creates a conflict:

• If KDE is set to Sleep, it calls systemd-suspend.service directly, bypassing your logind.conf suspend-then-hibernate setting entirely.
• If KDE is set to Do Nothing, it places an inhibitor lock that prevents the system from sleeping at all.

There is no KDE GUI option for “Suspend then Hibernate.” The solution is to leave KDE set to “Sleep” but redirect what the underlying systemd service actually does.

Configure KDE

#

Open System Settings → Power Management. Set “When laptop lid closed” to Sleep for both AC and Battery profiles.

Create a systemd drop-in override

#

Rather than symlinking the service file (which a systemd package update can silently break), we create a drop-in override that survives updates:

sudo mkdir -p /etc/systemd/system/systemd-suspend.service.d

cat << 'EOF' | sudo tee /etc/systemd/system/systemd-suspend.service.d/override.conf
[Service]
ExecStart=
ExecStart=/usr/lib/systemd/systemd-sleep suspend-then-hibernate
EOF

sudo systemctl daemon-reload

The empty ExecStart= line is required — systemd accumulates ExecStart entries additively, so the blank line clears the original command before setting the replacement. Without it, both commands would run and the unit would fail.

Verify the override is active:

systemctl cat systemd-suspend.service

You should see the original unit file followed by your override under a # /etc/systemd/system/systemd-suspend.service.d/override.conf header.

Why this works

#

The chain is: lid close → KDE PowerDevil → “Sleep” → systemd-suspend.service → (override) → suspend-then-hibernate. KDE thinks it is triggering a normal suspend, but the drop-in redirects the call. Package updates replace files in /lib/systemd/system/ but never touch /etc/systemd/system/, so the override persists.

The Result

#

When you close the lid:

1. KDE’s PowerDevil fires its “Sleep” action.
2. The overridden systemd-suspend.service triggers suspend-then-hibernate.
3. The system enters hardware S3 deep sleep — CPU powers down, RAM stays on, NVMe enters its low-power idle state.
4. An RTC (real-time clock) alarm is set for the configured delay (120 minutes in this example).
5. After the delay, the system briefly wakes, writes the contents of RAM to the swapfile, and powers off completely (true hibernation).
6. On the next power-on, the kernel finds the hibernation image via the resume parameters and restores the session.

Battery drain during the S3 phase is minimal (typically < 1% per hour on modern ThinkPads). After hibernation kicks in, drain is zero — the machine is fully powered off.

Troubleshooting

#

Hibernation fails silently (system wakes from S3 but doesn’t hibernate): Check that your swapfile is large enough and that the resume and resume_offset parameters in GRUB match your current swapfile. If you recreate the swapfile, the offset will change.

# Verify current offset
sudo filefrag -v /swapfile | awk 'NR==4 {print $4}' | tr -d '.'

System doesn’t wake from S3 at all: Check dmesg after a manual wake for RTC alarm errors. Some BIOS versions have buggy RTC wake implementations — updating the BIOS firmware can help.

KDE still overrides behavior after update: Re-check that PowerDevil is set to “Sleep” (not “Shutdown” or “Do Nothing”) and that the drop-in is still in place:

systemctl cat systemd-suspend.service
